Lens Calculator
1. Choose Camera Image Size. 2. Enter object distance. 3. Enter horizontal view needed. 4. Click the Calculate button to display focal length needed



Object Distance   ft
Horizontal View Needed   ft


Focal Length Needed   mm

MP Motorized Day/Night Zoom Lense Lineup





MODEL Series/Resolution Format Focal Length F.NO. / IRIS Mount
VZ-D2.7X24MIR-MP-6W 4MP 1" 24 - 65 ( 2.7X ) mm F2.0 / 3-Motor C
VZ-D2.7X24MIR-MPZFI-6W 4MP 1" 24 - 65 ( 2.7X ) mm F2.0 / 3 Motor w/Presets C
VZ-D2.7X24RDCIR-MP-4W 4MP 1" 24 - 65 ( 2.7X ) mm F2.0 / DC C
VZ-E16X9DCIR-MP-4W 2MP 1.8" 9 - 144 ( 16X ) mm F1.6 / DC(IR) C
VZ-E16X9DCIR-MP-PZF-4W 2MP 1.8" 9 - 144 ( 16X ) mm F1.6 / DC(IR) w/Presets C


Scroll to learn more

Key Features























HIGH QUALITY LENSES



To achieve the full resolution of a megapixel camera, it is essential to use a high quality megapixel lens. Overall image quality is greatly affected by the quality of the optical image directed onto the image sensor.



ViewZ Megapixel lenses provide high contrast, brightness and sharpness across the entire image plane. Non-megapixel lenses will not fully display the resolution of megapixel sensor, especially in the corner areas of the image.



Back to Features












HIGH-END MOTORIZED ZOOM



ViewZ high resolution megapixel zooms offer a wide range of manual and motorized versions including our 35X day/night model suited for long range port and border surveillance. The compact and lightweight design allows establishment of compact remote surveillance systems. Many models are available with preset potentiometers.



Back to Features














24 / 7 SURVEILLANCE APPLICATION



There is a growing need for compact, high quality lenses for 24/7 surveillance applications such as parking lots, factory premises and streets. Continuous surveillance is also required for public facilities such as airports, harbors, highways and border patrol, requiring more versatile focal lengths and higher zoom ratios.



ViewZ Day/Night (IR) lenses respond to infrared illumination to capture clear, corrected images in all lighting conditions. We offer a lineup of lenses from the standard focal length of 2.8-12 mm to the diverse focal length of 8-80mm featuring ED (Extra-low Dispersion) glass for maximum focus shift correction under IR and excellent daytime performance.





Back to Features
















MADE IN JAPAN



All ViewZ lenses are all made in JAPAN and we produce superior quality products in a small-sized manufacturing environment, where we respect craftsmanship.



Viewz offers over 180 advanced lens solutions such as Fixed, Vari-Focal, and Zoom in both standard and megapixel resolutions for a variety of applications. Each ViewZ lens is backed by our 4-year warranty.



Back to Features












3-MOTOR SYSTEM



ViewZ motorized zoom lenses (3-motor) are ideal for any indoor and outdoor applications. Featuring world-class design, ViewZ lenses bring together great quality glass optics, robust construction, and durability to ensure state-of-art performance.



* VZ-D2.7X24MIR-MP-6W



Back to Features












DC-TYPE AUTO-IRIS



An auto-iris lens without an internal circuit to control the iris. All iris control voltages come from a circuit located within the camera to adjust the iris for changing light levels. DC-type lenses are recommended for use in inconsistent lighting conditions (e.g. outdoors). These are sometimes referred to as DD (Direct Drive) lenses.



* VZ-B35X10DCIR-MP-4W, VZ-B35X20DCIR-MP-4W, VZ-D2.7X24RDCIR-MP-4W



Back to Features












VARIOUS FOCAL LENGTH



Focal length is the basic characteristic of a lens and determines how much magnification it provides. The focal length defines the area of the scene that can be viewed with a given sensor size and is expressed in millimeters (mm).



ViewZ lenses have many options when it comes to focal length selection to fit your application.



Back to Features










C & CS MOUNT



CCTV lenses are available in two different lens mounts. C-mount lenses have a flange back distance of 17.526mm vs. 12.5mm for CS-mount lenses. Many of today’s cameras can accept either type of lens, but it is important to make sure that camera and lens are compatible and set up properly.



C-mount lenses have a flange back distance of 17.526mm vs. 12.5mm for CS-mount lenses. C-mount lenses can be used on CS-mount cameras by utilizing a 5mm adapter or adjusting the camera for C-mount lenses.



CS-mount lenses have a flange back distance of 12.5mm vs. 17.526mm for C-mount lenses. Because of the shorter back focal distance, CS-mount lenses can only be used on CS-mount cameras. Your picture will be out of focus if you use a CS-mount lens on a C-mount camera.





Back to Features




















PEACE OF MIND



ViewZ products are proudly designed and produced with the highest performance and quality in mind. As a result, each ViewZ lens is backed by our 4-year Parts and Labor Warranty. In the rare event that one of our products does not perform according to our specifications or our customer's expectations, ViewZ on-site Technical Support staff will work diligently to resolve each case. ViewZ may also choose to provide an Advanced Replacement unit depending on the details of each individual case.
